Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
700
mA
Peak wavelength
λ
940
nm
Brightness
ΦE
2700
mW
IE
952
mW/sr
Dimension
l
7.0
mm
w
7.0
mm
h
1.1
mm
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| LZ4-01R708-0000 | ΦE = 1.6 ... 3.8 W (IF = 700 mA) | Q65113A1753 | Full production |
