Details
Parameters
Color of emission
True Green (513-545 nm)
Peak wavelength
λ
520
nm
Current
IF
110
mA
Brightness
ΦE
50
mW
Beam angle
∢
7
°
∢
22
°
Dimension
l
3.8
mm
w
3.2
mm
h
3.15
mm
Operating temperature
Top
min.
-20
°C
Top
max.
60
°C
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| PLT3 520FB | Popt = N/A (N/A), (Popt=50 mW typ.) | Q65113A4974 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
