OSRAM Chip, SPL DS90A_3

×

Description

Nanostack Pulsed Laser Diode
Datasheet
SPL DS90A_3
English
Download
Select & order
Contact us Support

Details

Parameters

Color of emission
Infrared (>800 nm)
Peak wavelength
λ
911 nm
Current
IF
999 mA
Brightness
ΦE
120000 mW
Beam angle
∢
10 °
∢
25 °
Dimension
l
0.6 mm
w
0.4 mm
h
0.115 mm
Operating temperature
Top min.
-40 °C
Top max.
105 °C

Ordering information

Product Type Description Ordering code Availability
SPL DS90A_3 Popt = 120 W typ , (IF=40 A) Q65112A3764 Full production

Downloads

Datasheets
SPL DS90A_3 · Datasheet · PDF · en_US

Application note
Using visible InGaN laser diodes · Product related · PDF · en_US
Time-of-flight (ToF) measurement using pulse lasers · Product related · PDF · en_US
Operating the pulsed laser diode SPL PLxx · Product related · PDF · en_US
IR Pulsed Laser SPL DS90A_3 · Product related · PDF · en_US
Customer complaint management — Details on return shipments for failure analysis request (FAR) · General information · PDF · en_US
Fundamentals of LED handling · Handling recommendations · PDF · en_US
Dry pack information · Handling recommendations · PDF · en_US

Resources
CAD Data · CAD Data · FOLDER
Optical Simulation · Optical Simulation · FOLDER

Images
SPL_DS90A_3_photo · Images · EPS
