ams BELICE-SD

Description

BELICE-SD is a proprietary infrared dot-pattern illuminator for stereoscopic imaging platforms. It produces a very high-contrast dot pattern that stereo-matching algorithms can use to address low-texture situations and achieve high-accuracy depth maps. An additional benefit of the dot pattern is a reduction of the computational load required to perform the depth calculation.
The BELICE-SD dot-pattern illuminator is provided in a miniature package that is compatible with standard lead-free reflow processes. As such, it can be successfully used onboard of a great variety of 3D sensing platforms, from mobile to IoT to robotics.
A pair of BELICE-SD emitters produce approximately 10k dots at 850nm. A 940nm version is currently under development.

Details

Features

  • High-contrast dot-pattern
  • High electro-optical efficiency
  • Small package size

Benefits

  • Enables fast and accurate depth sensing
  • Low power consumption for mobile and wall-plugged platforms
  • Ease of implementation onboard a variety of platforms such as mobile, IoT and robotics

Ordering codes

Product Type Description Order No. Availability
APDE-00 Q65114A0128
APDB-00 Q65114A0129
