Details
Features
- Interlock based eye-safety functionality
- AECQ-102 and ISO 26262 qualification
- Optimized FoI for cabin monitoring applications
Benefits
- Integrated robust eye safety
- High power and homogenous IR illlumination for better performing In-cabin sensing systems
- ISO 26262 qualification for safety applications
Parameters
Nominal Output Power
[mW]
4000 @100µs/2%/5A/25ºC
Wavelength
[nm]
940
Field of Illumination
[°]
115x85
Footprint
[mm]
4.0x4.0x1.21
Application fields
Ordering codes
Product Type | Description | Order No. | Availability |
---|---|---|---|
AWBC-00 | Q65114A0205 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
Downloads
For other documents visit our
Download center
Datasheets
TARA2000-940-W-AUT-SAFE Automotive Infrared VCSEL Illuminator With On-Diffuser Eye Safety Mechanism
Datasheet
Technical documents
Infrared LED and VCSEL Illuminators for In-Cabin Sensing
Factsheet
Environmental documents
TARA2000-940-W-AUT-SAFE_RC001057_1-00
RoHS certificate
Images
TARA2000-AUT-SAFE_36x22.4mm_cmyk.eps
