Details
Parameters
Color of emission
Infrared (>800 nm)
Peak wavelength
λ
940
nm
Current
IF
4000
mA
Brightness
ΦE
3000
mW
Beam angle
∢
63
°
∢
50
°
Dimension
l
2.4
mm
w
3.3
mm
h
1.2
mm
Operating temperature
Top
min.
-20
°C
Top
max.
85
°C
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| V105Q121A-940 | Popt= 3 W typ. (IF = 4 A) | Q65113A1626 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
