OSRAM BIDOS® P2835 C, V107C031A-940
Discontinued
×
Discontinued
Details
Parameters
Color of emission
Infrared (>800 nm)
Peak wavelength
λ
940
nm
Current
IF
5000
mA
Brightness
ΦE
4000
mW
Beam angle
∢
72
°
∢
58
°
Dimension
l
3.5
mm
w
2.8
mm
h
1.5
mm
Operating temperature
Top
min.
-40
°C
Top
max.
110
°C
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| V107C031A-940 | Popt= 4 W typ. (IF = 5 A) | Q65113A2902 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
Downloads
For other documents visit our
Download center
Datasheets
V107C031A-940
Datasheet
Application note
Resources
CAD Data
CAD Data
Optical Simulation
Optical Simulation
Images
PLPVEC2 850A_picture
