Details
Parameters
Color of emission
Yellow (580-595 nm)
Electrical power
0.04
W
Low
Brightness
ΦV
0.879
lm
IV
0.163
cd
ΦE
1.71
mW
IE
0.316
mW/sr
Beam angle
∢
160
°
Operating temperature
Top
min.
-30
°C
Top
max.
85
°C
Dimension
l
2.0
mm
w
1.3
mm
h
0.8
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LY R976-PS-36 | Iv = 45 ... 280 mcd (IF = 20 mA) | Q62702P5177 |
