Details
Parameters
Color of emission
Red (612-630 nm)
Electrical power
6.8
W
Ultra High
Brightness
ΦV
500
lm
IV
240
cd
ΦE
2500
mW
IE
1200
mW/sr
Beam angle
∢
100
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
7.0
mm
w
7.0
mm
h
3.7
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LZ4-00R108-0000 | ΦV = 356 ... 868 lm (IF = 700 mA) | Q65113A1760 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
