Details
Parameters
Color of emission
True Green (513-545 nm)
Electrical power
0.0035
W
Low
Brightness
Ī¦V
0.662
lm
IV
0.21
cd
Ī¦E
1.3
mW
IE
0.412
mW/sr
Beam angle
ā¢
120
Ā°
Operating temperature
Top
min.
-40
Ā°C
Top
max.
100
Ā°C
Dimension
l
2.2
mm
w
1.4
mm
h
1.3
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LT M67D-R2S2-36-L6Z6-1.5 | Iv = 140 ... 280 mcd (IF = 1.5 mA) | Q65113A4944 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
