Details
Parameters
Color of emission
Yellow (580-595 nm)
Electrical power
2.2
W
High
Brightness
ΦV
175
lm
IV
58
cd
ΦE
503
mW
IE
167
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
1.9
mm
w
1.5
mm
h
0.752
mm
Application fields
Ordering codes
Product Type | Description | Order No. | Availability |
---|---|---|---|
LCY CEUP-6L6M-5F5G-8E8G | ΦV = 125 ... 224 lm (IF = 700 mA) | Q65111A7159 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
