Details
Parameters
Color of emission
Yellow (580-595 nm)
Electrical power
3.3
W
High
Brightness
ΦV
280
lm
IV
94
cd
ΦE
789
mW
IE
265
mW/sr
ΦP
1.43
µmol/s
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
135
°C
Dimension
l
1.9
mm
w
1.5
mm
h
0.74
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| KY CWLNM2.FY-Y2Y7-5F5G-2686 | ΦV = 235 ... 325 lm (IF = 1000 mA) | Q65113A9476 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
