Details
Parameters
Color of emission
Hyper Red (635-666 nm)
Electrical power
1.4
W
High
Brightness
ΦV
68.3
lm
IV
21.4
cd
ΦE
1100
mW
IE
345
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
3
mm
w
3
mm
h
2.17
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| GH CSSRM6.24-VAA3-1-1 | ΦE = 1095 ... 1210 mW (IF = 700 mA) | Q65113A8446 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GH CSSRM6.24-V8A2-1-1 | ΦE = 1035 ... 1165 mW (IF = 700 mA) | Q65113A5606 | |
| GH CSSRM6.24-V9A2-1-1 | ΦE = 1075 ... 1165 mW (IF = 700 mA) | Q65113A7191 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
