Details
Parameters
Color of emission
Deep Blue (439-461 nm)
Electrical power
2.1
W
High
Brightness
Ī¦V
34.9
lm
IV
11.5
cd
Ī¦E
1350
mW
IE
445
mW/sr
Beam angle
ā¢
120
Ā°
Operating temperature
Top
min.
-40
Ā°C
Top
max.
120
Ā°C
Dimension
l
3.1
mm
w
3.1
mm
h
1.95
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LD CQAR-ARAT-24-1 | Ī¦E = 1300 ... 1640 mW (IF = 700 mA) | Q65112A0993 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| LD CQAR-AQAS-24-1 | Ī¦E = 1210 ... 1500 mW (IF = 700 mA) | Q65112A0992 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
