Details
Parameters
Color of emission
Amber (609-624 nm)
Electrical power
0.77
W
High
Brightness
Ī¦V
79.2
lm
IV
44.3
cd
Ī¦E
322
mW
IE
180
mW/sr
Beam angle
ā¢
80
Ā°
Operating temperature
Top
min.
-40
Ā°C
Top
max.
120
Ā°C
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LA CP7P-KQKS-W3 | = 76.30 ... 97.00 lm (IF = 350 mA) | Q65111A2282 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| LA CP7P-JUKR-34 | = 65.80 ... 89.20 lm (IF = 350 mA) | Q65111A3124 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| LA CP7P-JUKQ-W4 | = 65.80 ... 82.00 lm (IF = 350 mA) | Q65111A2062 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| LA CP7P-KPKR-W4 | = 71.00 ... 89.20 lm (IF = 350 mA) | Q65111A2063 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
