Details
Parameters
Color of emission
Blue (450-480 nm)
Electrical power
3.0
W
High
Brightness
ΦV
34.5
lm
IV
11.6
cd
ΦE
1350
mW
IE
452
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
3.0
mm
w
3.0
mm
h
0.75
mm
Device qualification
AEC-Q102
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| KB CSLNM1.14-4V7A-46 | ΦE = 1000 ... 1590 mW (IF = 1000 mA) | Q65112A3602 | Full production |
| KB CSLNM1.14-4V7A-46-AM | ΦE = 1000 ... 1590 mW (IF = 1000 mA) | Q65113A3683 | Full production |
| KB CSLNM1.14-5A8A-23 | ΦE = 1120 ... 1800 mW (IF = 1000 mA) | Q65113A1588 | Full production |
| KB CSLNM1.14-5A8A-23-AM | ΦE = 1120 ... 1800 mW (IF = 1000 mA) | Q65113A4766 | Full production |
