Details
Parameters
Color of emission
Amber (609-624 nm)
Electrical power
2.4
W
High
Brightness
ΦV
290
lm
IV
104
cd
ΦE
1200
mW
IE
430
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
105
°C
Dimension
l
5.77
mm
w
4.7
mm
h
1.25
mm
Device qualification
AEC-Q102
Application fields
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| LE A Q7WN-7M6N-24 | ΦV = 224 ... 355 lm (IF = 1000 mA) | Q65113A8299 | Full production |
