Details
Parameters
Color of emission
Amber (609-624 nm)
Electrical power
3.2
W
High
Brightness
ΦV
215
lm
IV
77.3
cd
ΦE
889
mW
IE
319
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Dimension
l
3.9
mm
w
3.65
mm
h
1.2
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LE A Q8WP-LZMZ-23-AM | ΦV = 150 ... 280 lm (IF = 1400 mA) | Q65113A3522 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| LE A Q8WP-LZMZ-23 | ΦV = 150 ... 280 lm (IF = 1400 mA) | Q65113A2443 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
