Details
Parameters
Color of emission
True Green (513-545 nm)
Electrical power
2.9
W
High
Brightness
ΦV
540
lm
IV
179
cd
ΦE
1140
mW
IE
377
mW/sr
ΦP
2.37
µmol/s
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
5.77
mm
w
4.7
mm
h
1.25
mm
Device qualification
AEC-Q102
Application fields
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| LE T Q7WN-5P7P-34 | ΦV = 450 ... 630 lm (IF = 1000 mA) | Q65113A8296 | Full production |
