Details
Parameters
Color of emission
Amber (609-624 nm)
Electrical power
46.0
W
Ultra High
Brightness
Ī¦V
2770
lm
IV
928
cd
Ī¦E
10100
mW
IE
3370
mW/sr
Beam angle
ā¢
120
Ā°
Dimension
l
27.0
mm
w
15.5
mm
h
1.5
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LE A P1MR-SSTQ-2 | Ī¦V = 2240 ... 3300 lm (IF = 8000 mA) | Q65113A2122 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
