Details
Parameters
Color of emission
Blue (450-480 nm)
Electrical power
80.0
W
Ultra High
Brightness
ΦV
1120
lm
IV
403
cd
ΦE
25500
mW
IE
9170
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
27.0
mm
w
15.5
mm
h
2.1
mm
Ordering codes
Product Type | Description | Order No. | Availability |
---|---|---|---|
LE B P2W-GXHX-24 | Φe = 18 ... 33 W (IF = 24000 mA) | Q65112A4110 | |
LE B P2W-GXHX-VW | Φe = 18 ... 33 W (IF = 24000 mA) | Q65112A4336 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
