Details
Parameters
Color of emission
Red (612-630 nm)
Electrical power
0.31
W
Mid
Brightness
ΦV
29.2
lm
IV
9.8
cd
ΦE
167
mW
IE
55.9
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
110
°C
Dimension
l
4.8
mm
w
4.8
mm
h
3.8
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LR B6SP-DBFA-1-G3R3 | Iv = 5.6 ... 14.0 cd (IF = 140 mA) | Q65112A9765 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
