Details
Parameters
Color of emission
Amber (609-624 nm)
Electrical power
0.11
W
Low
Brightness
ΦV
10.2
lm
IV
9.25
cd
ΦE
40.6
mW
IE
36.8
mW/sr
Beam angle
∢
60
°
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Dimension
l
3.2
mm
w
2.8
mm
h
3.5
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LA E65F-T2V2-1-2A2B+DBFA-24-3A4B |
Iv = 355 ... 1120 mcd (IF□=□4□mA) Iv = 5600 ... 14000 mcd (IF□=□50□mA) |
Q65112A4802 | |
| LA E65F-DAFA-24-3A4B | Iv = 4500 ... 14000 mcd (IF = 50 mA) | Q65112A4803 |
