Details
Parameters
Color of emission
Super Red (627-639 nm)
Electrical power
0.11
W
Low
Brightness
ΦV
5.9
lm
IV
20.5
cd
ΦE
45.4
mW
IE
158
mW/sr
Beam angle
∢
30
°
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Dimension
l
3.2
mm
w
2.8
mm
h
3.8
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LS E63F-EAFB-1-1 | Ev = 7100 ... 18000 lx (IF = 50 mA) | Q65111A3723 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
