Details
Parameters
Color of emission
True Green (513-545 nm)
Electrical power
0.084
W
Low
Brightness
ΦV
5.97
lm
IV
1.96
cd
ΦE
11.7
mW
IE
3.84
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
110
°C
Dimension
l
3.2
mm
w
2.8
mm
h
1.9
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LT E6SG-BACA-36-U686 | Iv = 1800 ... 3550 mcd (IF = 30 mA) | Q65113A4324 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
