Details
Parameters
Color of emission
Orange (600-609 nm)
Electrical power
0.04
W
Low
Brightness
ΦV
0.535
lm
IV
0.146
cd
ΦE
1.45
mW
IE
0.397
mW/sr
Beam angle
∢
130
°
∢
130
°
Operating temperature
Top
min.
-40
°C
Top
max.
105
°C
Dimension
l
1.6
mm
w
0.8
mm
h
0.8
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| KO EELP41.22-Q1S2-25-A8J8 | Iv = 71 ... 280 mcd (IF = 20 mA) | Q65113A7468 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
