Details
Parameters
Color of emission
Red (612-630 nm)
Electrical power
0.22
W
Mid
Brightness
ΦV
28.3
lm
IV
9.27
cd
ΦE
135
mW
IE
44.2
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
110
°C
Dimension
l
2.2
mm
w
2.2
mm
h
0.65
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| KR DDLM32.23-GQHS-25-D1G2 | ΦV = 19.4 ... 39.0 lm (IF = 100 mA) | Q65113A5717 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
