Details
Parameters
Color of emission
Blue (450-480 nm)
Electrical power
0.057
W
Low
Brightness
ΦV
2.1
lm
IV
2.23
cd
ΦE
37.1
mW
IE
39.4
mW/sr
Beam angle
∢
55
°
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Dimension
l
3.2
mm
w
2.8
mm
h
3.35
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LB T66G-V2CA-59-Z484 | Iv = 900 ... 3550 mcd (IF = 20 mA) | Q65112A7291 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
