Details
Parameters
Color of emission
Super Red (627-639 nm)
Green (565-575 nm)
Electrical power
0.04
W
0.042
W
Low
Low
Brightness
ΦV
0.227
lm
IV
0.074
cd
ΦE
0.355
mW
IE
0.116
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Dimension
l
3.3
mm
w
3.0
mm
h
1.9
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LSG T676-P7R-1-0+N7Q-24-0 |
|
Q65113A1229 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
