Details
Parameters
Color of emission
Super Red (627-639 nm)
Electrical power
0.02
W
Low
Brightness
IV
0.006
cd
Operating temperature
Top
min.
-40
Ā°C
Top
max.
100
Ā°C
Dimension
l
3.5
mm
w
2.8
mm
h
1.9
mm
Application fields
Ordering codes
Product Type | Description | Order No. | Availability |
---|---|---|---|
SFH 331-JK | Iv = 4 ... 12.5ā”mcd (IFā”=ā”10ā”mA) IPCE = ā„ 16 (Eeā”=ā”0.1ā”mW/cmĀ²) | Q65110A2821 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
