Details
Parameters
Color of emission
White
CRI
80
Electrical power
0.18
W
Mid
Brightness
ΦV
36
lm
IV
11.9
cd
ΦE
107
mW
IE
35.2
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
105
°C
Dimension
l
3.25
mm
w
3.25
mm
h
0.75
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| GW QSLMS3.EM-H2H5-XX510-1 | ΦV = 30.0 ... 36.0 lm, Mountingmethode:SDCM 5, 2200 K (IF = 65 mA) | Q65113A6183 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H7H9-XX51-1-TK | ΦV = 37.5 ... 42.0 lm, Mountingmethode:SDCM 5, 6500 K (IF = 65 mA) | Q65113A9256 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H6H9-XX56-1-TK | ΦV = 36.0 ... 42.0 lm, Mountingmethode:SDCM 5, 3500 K (IF = 65 mA) | Q65113A9261 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H6H9-XX51-1 | ΦV = 36.0 ... 42.0 lm, Mountingmethode:SDCM 5, 6500 K (IF = 65 mA) | Q65113A6190 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H7H9-XX53-1 | ΦV = 37.5 ... 42.0 lm, Mountingmethode:SDCM 5, 5000 K (IF = 65 mA) | Q65113A6195 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H4H7-XX58-1 | ΦV = 33.0 ... 39.0 lm, Mountingmethode:SDCM 5, 2700 K (IF = 65 mA) | Q65113A6184 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H7H9-XX55-1-TK | ΦV = 37.5 ... 42.0 lm, Mountingmethode:SDCM 5, 4000 K (IF = 65 mA) | Q65113A9253 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H5H8-XX56-1 | ΦV = 34.5 ... 40.5 lm, Mountingmethode:SDCM 5, 3500 K (IF = 65 mA) | Q65113A6187 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H7H9-XX52-1-TK | ΦV = 37.5 ... 42.0 lm, Mountingmethode:SDCM 5, 5700 K (IF = 65 mA) | Q65113A9255 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H7H9-XX53-1-TK | ΦV = 37.5 ... 42.0 lm, Mountingmethode:SDCM 5, 5000 K (IF = 65 mA) | Q65113A9254 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H4H7-XX58-1-TK | ΦV = 33.0 ... 39.0 lm, Mountingmethode:SDCM 5, 2700 K (IF = 65 mA) | Q65113A9265 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H2H5-XX510-1-TK | ΦV = 30.0 ... 36.0 lm, Mountingmethode:SDCM 5, 2200 K (IF = 65 mA) | Q65113A9213 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H7H9-XX55-1 | ΦV = 37.5 ... 42.0 lm, Mountingmethode:SDCM 5, 4000 K (IF = 65 mA) | Q65113A6196 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H5H8-XX57-1 | ΦV = 34.5 ... 40.5 lm, Mountingmethode:SDCM 5, 3000 K (IF = 65 mA) | Q65113A6188 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H7H9-XX52-1 | ΦV = 37.5 ... 42.0 lm, Mountingmethode:SDCM 5, 5700 K (IF = 65 mA) | Q65113A6194 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW QSLMS3.EM-H5H8-XX57-1-TK | ΦV = 34.5 ... 40.5 lm, Mountingmethode:SDCM 5, 3000 K (IF = 65 mA) | Q65113A9263 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
