Details
Parameters
Color of emission
White
Electrical power
15.0
W
Ultra High
Brightness
ΦV
1820
lm
IV
605
cd
ΦE
5620
mW
IE
1870
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
6.4
mm
w
3.75
mm
h
0.43
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| KW H5L531.TE-Z7R7-ebvFfcbB46-RS5R | ΦV = 1400 ... 2240 lm (IF = 1000 mA) | Q65112A4051 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
