Details
Parameters
Color of emission
White
CRI
90
Electrical power
1.0
W
High
Brightness
Ī¦V
103
lm
IV
54.2
cd
Ī¦E
366
mW
IE
193
mW/sr
Beam angle
ā¢
80
Ā°
Operating temperature
Top
min.
-40
Ā°C
Top
max.
125
Ā°C
Dimension
l
3.0
mm
w
3.0
mm
h
2.21
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| GW CS8PM1.CM-KSKU-XX58-1 | Ī¦V = 89 ... 112 lm, 2700 K (IF = 350 mA) | Q65112A1018 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW CS8PM1.CM-KTLP-XX56-1 | Ī¦V = 97 ... 121 lm, 3500 K (IF = 350 mA) | Q65112A1157 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
| GW CS8PM1.CM-KULQ-XX55-1 | Ī¦V = 104 ... 130 lm, 4000 K (IF = 350 mA) | Q65112A1050 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
| GW CS8PM1.CM-KTLP-XX57-1 | Ī¦V = 97 ... 121 lm, 3000 K (IF = 350 mA) | Q65112A0956 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
