Details
Parameters
Color of emission
White
CRI
90
Electrical power
0.84
W
High
Brightness
ΦV
106
lm
IV
36.3
cd
ΦE
349
mW
IE
119
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
110
°C
Dimension
l
3.0
mm
w
3.0
mm
h
0.65
mm
Device qualification
AEC-Q102
Application fields
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| KW DSL531.CC-KXLX-4U9X-N464 | ΦV = 71 ... 130 lm (IF = 140 mA) | Q65115A2669 | Pre-production |
| KW DSL531.CC-KXLX-4YC9-N464 | ΦV = 71 ... 130 lm (IF = 140 mA) | Q65115A2667 | Pre-production |
| KW DSL531.CC-KYLX-4C7E-N464 | ΦV = 82 ... 130 lm (IF = 140 mA) | Q65115A2662 | Pre-production |
| KW DSL531.CC-KYLX-4F8H-N464 | ΦV = 82 ... 130 lm (IF = 140 mA) | Q65115A2666 | Pre-production |
| KW DSL531.CC-KYLX-4I8K-N464 | ΦV = 82 ... 130 lm (IF = 140 mA) | Q65115A2664 | Pre-production |
| KW DSL531.CC-KYLX-4L8N-N464 | ΦV = 82 ... 130 lm (IF = 140 mA) | Q65115A2663 | Pre-production |
| KW DSL531.CC-KYLX-4O9Q-N464 | ΦV = 82 ... 130 lm (IF = 140 mA) | Q65115A2671 | Pre-production |
| KW DSL531.CC-KYLX-4R9T-N464 | ΦV = 82 ... 130 lm (IF = 140 mA) | Q65115A2670 | Pre-production |
