Details
Parameters
Color of emission
White
CRI
90
Electrical power
9.2
W
Ultra High
Brightness
ΦV
1580
lm
IV
529
cd
ΦE
5380
mW
IE
1810
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
105
°C
Dimension
l
13.5
mm
w
13.5
mm
h
1.5
mm
Application fields
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| GW KAFHB9.KM-C14-27S3 | ΦV = 1325 ... 1575 lm, 2700 K (IF = 270 mA) | Q65115A1917 | Full production |
| GW KAFHB9.KM-C15-30S3 | ΦV = 1395 ... 1655 lm, 3000 K (IF = 270 mA) | Q65115A1916 | Full production |
| GW KAFHB9.KM-C16-40S3 | ΦV = 1440 ... 1705 lm, 4000 K (IF = 270 mA) | Q65115A1883 | Full production |
| GW KAFHB9.KM-C17-50S3 | ΦV = 1445 ... 1715 lm, 5000 K (IF = 270 mA) | Q65115A1882 | Full production |
| GW KAFHB9.KM-C19-35S3 | ΦV = 1420 ... 1685 lm, 3500 K (IF = 270 mA) | Q65115A1897 | Full production |
| GW KAFHB9.KM-C23-57S3 | ΦV = 1495 ... 1770 lm, 5700 K (IF = 270 mA) | Q65115A1881 | Full production |
| GW KAFHB9.KM-C25-65S3 | ΦV = 1490 ... 1765 lm, 6500 K (IF = 270 mA) | Q65115A1880 | Full production |
