Details
Parameters
Color of emission
True Green (513-545 nm)
Hyper Red (635-666 nm)
Infrared (>800 nm)
Spectral range of sensitivity typ.
λ10%
min.
402
nm
λ10%
max.
694
nm
Radiant sensitive area
A
3.46
mm²
Dimension
l
7.5
mm
w
3.9
mm
h
0.9
mm
Operating temperature
Top
min.
-40
°C
Top
max.
85
°C
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 7072 | Green: Ie□=□3.8□mW/sr (typ.) (IF□=□20□mA) Red: Ie□=□4.8□mW/sr (typ.) (IF□=□20□mA) IR: Ie□=□3.9□mW/sr (typ.) (IF□=□20□mA) IR-Cut Detector: IP□= 1.1□µA, (typ.) (Ee□=□0.10 mW/cm², λ□=□530 nm) Broadband Detector: IP□=□1.1□µA, (typ.) (Ee□=□0.10□mW/cm², λ□=□940 nm) | Q65112A1516 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
