Details
Parameters
Photocurrent
1.7
µA
Spectral range of sensitivity typ.
λ10%
min.
400
nm
λ10%
max.
1100
nm
Radiant sensitive area
A
4.29
mm²
Beam angle
∢
120
°
Dimension
l
3.2
mm
w
2.0
mm
h
0.6
mm
Operating temperature
Top
min.
-40
°C
Top
max.
85
°C
Application fields
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| SFH 2707 | IP = 1.7 µA typ. (Ee=0.1 mW/cm²) | Q65115A1834 | Full production |
| SFH 2707H | IP = 1.7 µA typ. (Ee=0.1 mW/cm²) | Q65115A1835 | Full production |
