Details
Parameters
Photocurrent
6.3
µA
Fall time
tf
200.0
µs
Rise time
tf
200.0
µs
Spectral range of sensitivity typ.
λ10%
min.
400
nm
λ10%
max.
900
nm
Radiant sensitive area
A
7.02
mm²
Beam angle
∢
120
°
Dimension
l
6.45
mm
w
3.85
mm
h
1.15
mm
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Application fields
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| SFH 2430-Z | IP = ≥ 5.6 µA, (IP=6.3 µA typ.) (Ev=1000 lx) | Q65110A2673 | Full production |
