Details
Parameters
Photocurrent
2200.0
µA
Fall time
tf
13.0
µs
Rise time
tf
13.0
µs
Spectral range of sensitivity typ.
λ10%
min.
750
nm
λ10%
max.
1120
nm
Radiant sensitive area
A
0.11
mm²
Beam angle
∢
40
°
Dimension
l
5.7
mm
w
5.7
mm
h
8.6
mm
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Application fields
Ordering codes
Product Type | Description | Order No. | Availability |
---|---|---|---|
SFH 303 FA | IPCE = 1120 ... 4500 µA, (IPCE=2200 µA typ.) (Ee=0.5 mW/cm²) | Q62702P0958 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
SFH 303 FA-3/4 | IPCE = 1800 ... 4500 µA, (IPCE=2200 µA typ.) (Ee=0.5 mW/cm²) | Q62702P3587 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
