TOPLED®
TOPLED® product family - well known and established in the market.
ams OSRAM Power TOPLED® is a standard product in LED lighting. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications. Within the spectrum of visible and invisible light the TOPLED® product family offers solutions from backlighting up to basic gesture sensing and illumination in automotive interior applications. The latest product of this well established family ist the SFH 4246R, a new part for narrow space applications in the gesture sensing area.
Details
Features
- well established and broad low power LED portfolio
- visible colors: red (612-630 nm), superred (627-639 nm), amber (617 nm), orange (600-609 nm), green (565-575 nm), pure green (554-556 nm), true green (513-545 nm), blue (450-480 nm), white and yellow (580-595 nm).
- IR emitter for gesture sensing
- Package: white PLCC-2 package, colorless clear resin
- Chip technology: Thinfilm
- Corrosion Robustness Class: 3B
- ESD: 2 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM)
Benefits
- This well known TOPLED® product family is established in the LED lighting market and available in a wide variety of colors for various applications
- Easy to assemble on PCB with standard SMT reflow and providing enhanced design flexibility.
ams OSRAM' Power TOPLED® is a standard product in LED lighting. With our great experience in SMT LED we are able to offer a high quality product for all kind of applications. Within the spectrum of visible and invisible light the TOPLED® product family offers solutions from backlighting up to basic gesture sensing and illumination in automotive interior applications. The latest product of this well established family ist the SFH 4246R, a new part for narrow space applications in the gesture sensing area.
Details
Features
- Well established and broad low power LED portfolio
- visible colors: red (612-630 nm), superred (627-639 nm), amber (617 nm), orange (600-609 nm), green (565-575 nm), pure green (554-556 nm), true green (513-545 nm), blue (450-480 nm), white and yellow (580-595 nm).
- IR emitter for gesture sensing
- Package: white PLCC-2 package, colorless clear resin
- Chip technology: Thinfilm
- Corrosion Robustness Class: 3B
- ESD: 2 kV acc. to ANSI/ESDA/JEDEC JS-001 (HBM)
Benefits
- This well known TOPLED® product family is established in the LED lighting market and available in a wide variety of colors for various applications
- Easy to assemble on PCB with standard SMT reflow and providing enhanced design flexibility.
Details
Features
- Package: white PLCC-2 package, colored diffused resin or colorless clear resin
- Chip technology: InGaN or InGaAlP
- Typ. Radiation: 120° (Lambertian emitter)
- Corrosion Robustness Class: 3B
Benefits
- First SMT LED of ams OSRAM has evolved to a worldwide standard in LED packaging
- Industry standard device – long track of customer experience
- Long term production experience
- Broad portfolio
