Details
Parameters
Color of emission
Infrared (>800 nm)
Peak wavelength
Ī»
940
nm
Current
IF
15
mA
Brightness
Ī¦E
11
mW
Beam angle
ā¢
18
Ā°
ā¢
18
Ā°
Dimension
l
1.0
mm
w
0.5
mm
h
0.5
mm
Operating temperature
Top
min.
-40
Ā°C
Top
max.
85
Ā°C
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| PLPVYL1 940A_E | Popt = ā„ 7.7 mW, (Popt=11 mW typ.) (IF = 15 mA) | Q65112A9493 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
