Details
Parameters
Color of emission
Orange (600-609 nm)
Electrical power
0.04
W
Low
Brightness
ΦV
0.592
lm
IV
0.146
cd
ΦE
1.5
mW
IE
0.371
mW/sr
Beam angle
∢
140
°
Operating temperature
Top
min.
-30
°C
Top
max.
85
°C
Dimension
l
1.6
mm
w
0.8
mm
h
0.7
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LO Q976.01-P2R2-25-1 | Iv = 56 ... 180 mcd (IF = 20 mA) | Q65113A5256 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
