Details
Parameters
Color of emission
Yellow (580-595 nm)
Electrical power
1.1
W
High
Brightness
Ī¦V
55
lm
IV
18.3
cd
Ī¦E
188
mW
IE
62.5
mW/sr
Beam angle
ā¢
120
Ā°
Operating temperature
Top
min.
-40
Ā°C
Top
max.
125
Ā°C
Dimension
l
11.0
mm
w
6.0
mm
h
1.8
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LCY W5SM-HZJZ-5E-1 | Ī¦V = 39 ... 71 lm (IF = 350 mA) | Q65111A2605 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
