Details
Parameters
Color of emission
Blue (450-480 nm)
Electrical power
8.3
W
Ultra High
Brightness
ΦV
145
lm
IV
65.1
cd
ΦE
4270
mW
IE
1920
mW/sr
Beam angle
∢
100
°
Operating temperature
Top
min.
-40
°C
Top
max.
150
°C
Dimension
l
7.0
mm
w
7.0
mm
h
3.7
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LZ4-00B208-0000 | ΦV = 93 ... 228 lm (IF = 700 mA) | Q65113A1761 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
