Details
Parameters
Color of emission
Yellow (580-595 nm)
Electrical power
0.11
W
Low
Brightness
ΦV
19.8
lm
IV
6.28
cd
ΦE
39.9
mW
IE
12.7
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
100
°C
Dimension
l
3.3
mm
w
3.0
mm
h
1.8
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LYYYG6SF-CBEA-45 | Iv = 3550 ... 9000 mcd (IF = 50 mA) | Q65110A8529 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
