Replacement Products
OSRAM DURIS® E 2835, GH JTLPS1.24
The DURIS® E 2835 color family provide excellent color rendering and supreme efficacy in cost effective industry standard LED. DURIS® E 2835 never fails to impress with its performance on system level.
OSRAM OSCONIQ® P 3030, GH QSSPA1.24
The OSCONIQ P 3030 Colors family LED comes with well known superior robustness, high reliability, long lifetime, low thermal resistance. Compact and proven 3mm x 3mm package and established footprint. Perfectly addressing applications that demand for high efficiency and long lifetime.
Details
Parameters
Color of emission
Hyper Red (635-666 nm)
Electrical power
0.22
W
Mid
Brightness
ΦV
7.31
lm
IV
2.82
cd
ΦE
110
mW
IE
42.5
mW/sr
Beam angle
∢
105
°
Operating temperature
Top
min.
-40
°C
Top
max.
120
°C
Dimension
l
2.6
mm
w
2.2
mm
h
1.25
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| GH DASPA2.24-QMRK-1-1 | ΦE = 89 ... 130 mW (IF = 100 mA) | Q65112A7445 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
By clicking this button you will be transferred to the dedicated site of our logistics partner, Mouser Electronics where your purchase can be completed. Your payment and order details provided for this purpose will be shared between Mouser Electronics and ams OSRAM. More details on the data processing in question can be found in the Privacy Policy of the Mouser shop.
|
Downloads
Datasheets
Datasheet
Application note
Product related
Product related
Product related
Product related
General information
General information
General information
General information
General information
Handling recommendations
Handling recommendations
Soldering and processing
Electrical design
Electrical design
Electrical design
Electrical design
Resources
Images
Images
Tools
Horticulture
Calculation of different horticulture lighting scenarios with variations of LED configurations and ratios to realize the desired photon flux from the fixture and estimate the resulting photon flux density on the plants for a defined system setup.
Product selector
Find the right product.
More color LEDs
For a colorful life.
