Details
Parameters
Color of emission
Yellow (580-595 nm)
Electrical power
1.0
W
High
Brightness
ΦV
101
lm
IV
30.8
cd
ΦE
354
mW
IE
108
mW/sr
Beam angle
∢
120
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
3.0
mm
w
3.0
mm
h
0.75
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| GY QSSPA1.13-KSKU-5F5G-1 | ΦV = 89.2 ... 112.0 lm (IF = 350 mA) | Q65112A9196 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
