Details
Parameters
Color of emission
Yellow (580-595 nm)
Electrical power
1.0
W
High
Brightness
ΦV
124
lm
IV
36.1
cd
ΦE
351
mW
IE
102
mW/sr
Beam angle
∢
125
°
Operating temperature
Top
min.
-40
°C
Top
max.
120
°C
Dimension
l
3.0
mm
w
3.0
mm
h
1.68
mm
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LCY CLBP-KZLY-5F5G-8E8G | ΦV = 97 ... 150 lm (IF = 350 mA) | Q65112A3583 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
