Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
1000
mA
Peak wavelength
λ
860
nm
Brightness
ΦE
940
mW
IE
235
mW/sr
Beam angle
∢
130
°
∢
110
°
Dimension
l
3.75
mm
w
3.75
mm
h
1.53
mm
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| SFH 47167B | Ie = 200 ... 320 mW/sr, (Ie=235 mW/sr typ.) (IF = 1000 mA) | Q65113A7016 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
