Details
Parameters
Color of emission
Infrared (>800 nm)
Current
IF
1000
mA
Peak wavelength
λ
859
nm
Brightness
ΦE
1920
mW
IE
1800
mW/sr
Beam angle
∢
50
°
Dimension
l
3.75
mm
w
3.75
mm
h
2.94
mm
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Ordering information
| Product Type | Description | Ordering code | Availability |
|---|---|---|---|
| SFH 4717CS R33 | Ie = 1400 ... 2000 mW/sr, (Ie=1800 mW/sr typ.) (IF = 1000 mA) | Q65115A3392 | Pre-production |
